[KYUUBI #1613] Record the engine's applicationId in KyuubiSessionEvent

<!--
Thanks for sending a pull request!

Here are some tips for you:
  1. If this is your first time, please read our contributor guidelines: https://kyuubi.readthedocs.io/en/latest/community/contributions.html
  2. If the PR is related to an issue in https://github.com/apache/incubator-kyuubi/issues, add '[KYUUBI #XXXX]' in your PR title, e.g., '[KYUUBI #XXXX] Your PR title ...'.
  3. If the PR is unfinished, add '[WIP]' in your PR title, e.g., '[WIP][KYUUBI #XXXX] Your PR title ...'.
-->

### _Why are the changes needed?_
<!--
Please clarify why the changes are needed. For instance,
  1. If you add a feature, you can talk about the use case of it.
  2. If you fix a bug, you can clarify why it is a bug.
-->
Record the engine's applicationId in KyuubiSessionEvent. #1613

### _How was this patch tested?_
- [ ] Add some test cases that check the changes thoroughly including negative and positive cases if possible

- [X] Add screenshots for manual tests if appropriate
![image](https://user-images.githubusercontent.com/17894939/147318970-d939b3c0-c3c6-4f45-9e5b-c2de6402b5de.png)

- [X] [Run test](https://kyuubi.readthedocs.io/en/latest/develop_tools/testing.html#running-tests) locally before make a pull request

Closes #1622 from wForget/KYUUBI-1613.

Closes #1613

24e001f6 [Wang Zhen] comment
29453fc3 [Wang Zhen] [KYUUBI-1613] Record the engine's applicationId in KyuubiSessionEvent

Authored-by: Wang Zhen <wangzhen07@qiyi.com>
Signed-off-by: Kent Yao <yao@apache.org>

externals/kyuubi-spark-sql-engine/src/main/scala/org/apache/kyuubi/engine/spark/SparkThriftBinaryFrontendService.scala

@@ -20,12 +20,13 @@ package org.apache.kyuubi.engine.spark
 import org.apache.hadoop.io.Text
 import org.apache.hadoop.security.{Credentials, UserGroupInformation}
 import org.apache.hadoop.security.token.{Token, TokenIdentifier}
-import org.apache.hive.service.rpc.thrift.{TRenewDelegationTokenReq, TRenewDelegationTokenResp}
+import org.apache.hive.service.rpc.thrift.{TOpenSessionReq, TOpenSessionResp, TRenewDelegationTokenReq, TRenewDelegationTokenResp}
 import org.apache.spark.kyuubi.SparkContextHelper

 import org.apache.kyuubi.KyuubiSQLException
 import org.apache.kyuubi.ha.client.{EngineServiceDiscovery, ServiceDiscovery}
 import org.apache.kyuubi.service.{Serverable, Service, ThriftBinaryFrontendService}
+import org.apache.kyuubi.service.ThriftBinaryFrontendService.{CURRENT_SERVER_CONTEXT, OK_STATUS}
 import org.apache.kyuubi.util.KyuubiHadoopUtils

 class SparkThriftBinaryFrontendService(
@@ -63,6 +64,27 @@ class SparkThriftBinaryFrontendService(
     resp
   }

+  override def OpenSession(req: TOpenSessionReq): TOpenSessionResp = {
+    debug(req.toString)
+    info("Client protocol version: " + req.getClient_protocol)
+    val resp = new TOpenSessionResp
+    try {
+      val respConfiguration = new java.util.HashMap[String, String]()
+      respConfiguration.put("kyuubi.engine.id", sc.applicationId)
+
+      val sessionHandle = getSessionHandle(req, resp)
+      resp.setSessionHandle(sessionHandle.toTSessionHandle)
+      resp.setConfiguration(respConfiguration)
+      resp.setStatus(OK_STATUS)
+      Option(CURRENT_SERVER_CONTEXT.get()).foreach(_.setSessionHandle(sessionHandle))
+    } catch {
+      case e: Exception =>
+        error("Error opening session: ", e)
+        resp.setStatus(KyuubiSQLException.toTStatus(e, verbose = true))
+    }
+    resp
+  }
+
   private def addHiveToken(
       newTokens: Map[Text, Token[_ <: TokenIdentifier]],
       oldCreds: Credentials,

kyuubi-server/src/main/scala/org/apache/kyuubi/client/KyuubiSyncThriftClient.scala

@@ -38,6 +38,7 @@ class KyuubiSyncThriftClient private (protocol: TProtocol)
   extends TCLIService.Client(protocol) with Logging {

   @volatile private var _remoteSessionHandle: TSessionHandle = _
+  @volatile private var _engineId: Option[String] = _

   private val lock = new ReentrantLock()

@@ -54,6 +55,8 @@ class KyuubiSyncThriftClient private (protocol: TProtocol)
     } finally lock.unlock()
   }

+  def engineId: Option[String] = _engineId
+
   /**
    * Return the engine SessionHandle for kyuubi session so that we can get the same session id
    */
@@ -69,6 +72,9 @@ class KyuubiSyncThriftClient private (protocol: TProtocol)
     val resp = withLockAcquired(OpenSession(req))
     ThriftUtils.verifyTStatus(resp.getStatus)
     _remoteSessionHandle = resp.getSessionHandle
+    _engineId = Option(resp.getConfiguration)
+      .filter(_.containsKey("kyuubi.engine.id"))
+      .map(_.get("kyuubi.engine.id"))
     SessionHandle(_remoteSessionHandle, protocol)
   }


kyuubi-server/src/main/scala/org/apache/kyuubi/events/KyuubiSessionEvent.scala

@@ -36,6 +36,7 @@ import org.apache.kyuubi.session.AbstractSession
  * @param openedTime session opened time
  * @param endTime session end time
  * @param totalOperations how many queries and meta calls
+ * @param engineId engine id. For engine on yarn, it is applicationId.
  */
 case class KyuubiSessionEvent(
     sessionName: String,
@@ -46,6 +47,7 @@ case class KyuubiSessionEvent(
     startTime: Long,
     var sessionId: String = "",
     var remoteSessionId: String = "",
+    var engineId: String = "",
     var clientVersion: Int = -1,
     var openedTime: Long = -1L,
     var endTime: Long = -1L,

kyuubi-server/src/main/scala/org/apache/kyuubi/session/KyuubiSessionImpl.scala

@@ -86,6 +86,7 @@ class KyuubiSessionImpl(
       sessionEvent.sessionId = handle.identifier.toString
       sessionEvent.remoteSessionId = _engineSessionHandle.identifier.toString
       sessionEvent.clientVersion = handle.protocol.getValue
+      _client.engineId.foreach(e => sessionEvent.engineId = e)
       EventLoggingService.onEvent(sessionEvent)
     }
   }
